Tone Winner AD-7300 2.0 VERSION – 7 CHANNEL AMP 7X300W@8Ω
$1,975.00
Inventory Status
Product is on the way. Contact us for an updated ETA
-
Free Shipping
-
Experience audio brilliance with the Tonewinner AD-7300, a masterpiece that encapsulates cutting-edge technology and timeless design. As a leading name in the audio industry, Tonewinner brings you the AD-7300, a testament to its commitment to delivering superior sound quality and unmatched performance.
The Tonewinner AD-7300 is more than just a device; it’s a gateway to an auditory adventure. With meticulous attention to detail, this audio amplifier is designed to transform your listening experience into something extraordinary.
Key Features:
- Powerful Amplification: With a power output of 300W (8Ω) and 500W+ (4Ω), the AD-7300 delivers robust and dynamic sound that fills any room with clarity and richness.
- Advanced Technology: Incorporating advanced audio circuitry and high-quality components, this amplifier ensures accurate sound reproduction across the entire frequency spectrum.
- Elegant Design: The AD-7300’s sleek and sophisticated design seamlessly integrates into any living space, adding a touch of elegance to your audio setup.
- Versatile Connectivity: Equipped with a range of input options, including RCA and balanced XLR inputs, the AD-7300 easily connects to a variety of audio sources for seamless integration.
- Precise Control: The amplifier provides precise control over your audio, allowing you to fine-tune the sound to match your preferences and the acoustics of your room.
Features & Specifications
Audio Specifications: 120 Volts Test Results:
- Topology: Fully discrete, dual differential, high current, short signal path Class A/B – Class “H” power supply.
- Numbers of Channel: 7 Channels – High powered single channel modules.
- Power Output: ( Rated Power; THD <0.1% @ 120V (Tested @ AC 120V) – (AC 240V Will Increase the output wattage and maintain the THD<0.1%.)
- 300 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
- 507 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; one channel driven.
- 266 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
- 434 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
- 180+ watts RMS/channel; THD<0.1%; 8 Ohms; all Seven channels driven.
Audio Specifications: 240 Volts Test Results:
- Topology: Fully discrete, dual differential, high current, short signal path Class A/B – Class “H” power supply.
- Numbers of Channel: 7 Channels – High powered single channel modules.
- Power Output: ( Rated Power; THD <0.1% @ 240V (Tested @ AC 240V) – (AC 240V Will Increase the output wattage and maintain the THD<0.1%.)
- 324 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 8 Ohms; one channel driven.
- 584 watts RMS/channel; 20 Hz – 20 kHz; THD<0.1%; 4 Ohms; one channel driven.
- 307 watts RMS/channel; THD<0.1%; 8 Ohms; two channels driven.
- 500 watts RMS/channel; THD<0.1%; 4 Ohms; two channels driven.
- 200+ watts RMS/channel; THD<0.1%; 8 Ohms; all Seven channels driven.
- Power Bandwidth (at rated power; 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB).
- Broad-Band Frequency Response: 10 Hz to 70 kHz +0/-2 dB.
- THD + noise: < 0.006%; at 100 watts RMS; 1 kHz; 8 Ohms.
- Signal to Noise Ratio (8 Ohm load):
- > 106 dB; ref FTC rated power; unbalanced input (A-weighted).
- > 91 dB; ref 1 watt; unbalanced input (A-weighted).
- Minimum Recommended Load Impedance (per channel): 4 Ohms (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
- Damping Factor (8 Ohm load): > 149.
- Input Sensitivity (for rated power; 8 Ohm load): 1.5 V.
- Gain: 28 dB.
- Maximum Power Consumption: 2056 watts at 120V & 1128W at 240V
- Power Supply: 110V-240V- 15 Amps-20 Amps Auto Switching Class “H”Power Supply.
- Material: Aluminum
- Modules: Separate Heatsinks for individual modules.
- Color: Black
- Front Panel: Analogue meter with blue LED lights and Red Needle.
- G.W: 26.3KGS ( 57.98 Lb)
- Unit size: 17.48 L X 17.32 W X 7.76 H Inches
- Package size：22.52 L X 22.52 W X 12.64 H Inches
- Accessories: 120 Volts – 15 Amp Power cord cable Included
- Warranty: 2 years warranty
